Siyamuva now offers DWS systems from WM Packing as part of our broader warehousing, logistics and parcel-handling solution range. These solutions are designed for the measurement of parcel dimensions, weight and barcode data, with both Static DWS and Dynamic DWS options available depending on the application and workflow requirement.
What is a DWS system?
A DWS system combines dimensioning, weighing and scanning into one process. On the supplier pages, WM Packing presents these systems as solutions for collecting parcel information accurately and efficiently, with data uploaded to relevant management systems in real time. The range includes a Dynamic DWS System, which operates within a conveyor and sorting environment, and a Static DWS System, which is intended to support the manual processing of small parcels.
Dynamic DWS System
WM Packing describes the Dynamic DWS System as a solution located between the conveyor machine and sorting line. It is designed to measure weight, dimensions and barcode data automatically while parcels are moving, with software uploading the captured information to e-commerce, courier, logistics and warehouse management systems in real time.
According to the supplier, the Dynamic DWS System is intended for higher-throughput environments and can achieve up to 3600 pieces per hour in theory, with an adjustable conveying speed of 72 to 90 m/min. WM Packing also states that the system can read parcel weight, volume and barcode information accurately while the conveyor runs at 1.2 to 1.5 m/s, and that the design supports integration into existing assembly lines through a modular concept.
The supplier page also notes that the Dynamic DWS System supports 1D and 2D barcode scanning, with barcode positions on the top or side surface, and 1 to 6 side scanning customisable. Interface options are listed as RS 485/232 and Ethernet, with parcel handling capability from 0.1 kg to 50 kg and parcel dimensions from 100 mm x 100 mm x 50 mm up to 1200 mm x 800 mm x 800 mm. Published accuracy is listed as ±50 g for weight and ±10 mm for dimensions.
Static DWS System
WM Packing presents the Static DWS System as a solution for integrated dimensional measurement, weighing, scanning, identification of goods and data acquisition. The supplier states that it can greatly increase the speed of manual processing of small parcels and that it is suitable for small logistics outlets as well as small and large distribution centres.
The features listed for the Static DWS System include efficient collection by an intelligent system, easy deployment, and an all-in-one setup combining quick volume measurement, weighing, code reading and alarm functions. WM Packing also states that data can be uploaded and recorded in real time, and that the system can be customised according to customer process requirements.
The supplier lists the following specifications for the Static DWS System: 780 mm x 800 mm x 2450 mm frame dimensions, 780 mm ± 50 mm platform height, 600 mm x 600 mm x 600 mm 3D camera visual range, 730 mm x 550 mm scanning camera field of view with 650 mm depth of field, 4024 x 3036 resolution, 600 mm x 800 mm belt conveyor platform size, 0.5 m/s transmission speed, 60 kg electronic platform scale range, and WiFi/Ethernet communication interface.
Choosing between static and dynamic DWS systems
Based on the supplier information, the difference between the two solutions is primarily in how they are applied. The Dynamic DWS System is positioned for conveyor-based, automated parcel flow where items are measured and scanned while moving. The Static DWS System is positioned for the manual processing of small parcels where dimensioning, weighing and scanning are handled in a fixed station format.
DWS systems from Siyamuva
At Siyamuva, we focus on practical solutions that support warehousing, logistics and operational workflow requirements. By offering both Static DWS and Dynamic DWS systems, we can assist businesses looking for parcel data-capture solutions aligned with either manual parcel intake or conveyor-based sorting and handling environments.
Speak to Siyamuva about DWS systems
If you are looking for a solution for parcel dimensioning, weighing and scanning, speak to Siyamuva about our DWS systems offering and which option may be best suited to your application.
